Blazing Speeds Optimized for the PCIe Gen4 interface.
3D NAND Flash 3D NAND Flash technology brings dense storage in a compact design and allows storage capacities up to 4TB.
Security & Reliability Built-in data security and error-correction capabilities extend the longevity of the NAND flash storage.
MSI Center Migrate data with backup & restore functionality, monitor drive health and performance metrics in real-time in MSI Center.
5 Years Warranty MSI stands by the quality and reliability of their SSD’s with a 5 year limited warranty
Fiche Technique
Model Name
SPATIUM M461 PCIe 4.0 NVMe M.2
Capacity
500GB 1TB 2TB 4TB
Controller
PHISON E21T
Flash Memory
3D NAND
Form Factor
M.2 2280
Interface
PCIe Gen4x4, NVMe 1.4
Compatibility
PCIe Gen4 / Gen3 / Gen2 / G
Dimensions
80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s)
4700 / 5000 / 5000 / 5000
Sequential Write up to (MB/s)
1700 3200 4200 4200
Random Read 4KB up to (IOPS)
320,000 630,000 680,000 600,000
Random Write 4KB up to (IOPS)
400,000 750,000 880,000 850,000
Maximum Operating Power (W)
3.7 4.1 4.4 5.1
Idle Power PS3 (mW)
50
Low Power L1.2 (mW)
5
Operating Temperatures
0°C – 70°C
Storage Temperatures
-40°C – 85°C
Terabytes Written (TBW)
110 250 450 900
Mean Time Between Failure (MTBF)
Up to 1,500,000 Hours
Limited Warranty
5 Years, or the coverage for the maximum TBW as stated, whichever comes first
Advanced Features
TRIM (Performance Optimization, OS Support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition) Pyrite (Encryption, Data Security)
